SPECIFICATIONS

• 7 Inch color LCD, Touchscreen
• Flow cell and cuvette test mode compatible
• Real time curve showing
• 90 test items pre-programmed
• Memory for 10,000 sample results
• RS 232 interface, PC connecting
• 10 position for dry incubation 3 digital timers
• Test mode: Kinetic, End point, Two point, Absorbance
• Wave length: 7 standard filters, 340, 405, 492, 510, 546, 578, 630nm, 1 free position
• Absorbance Range: 0 ~ 4.500 Abs
• Sample Volume: 0 ~ 3000ul (>500ul recommend)
• Quality Control Curve: X, SD, CV%, L-J
• Flow Cell: 32 uL quartz glass, 10mm
• Light source: Quartz – Halogen 6V 10W lamp with long life
• CPU: ARM series high speed micro CPU
• Printer: Internal thermal sensitive printer
• Work Environment: Temperature 0 ~ 40°C, Humidity: <80%
• Power Supply: 100-240 VAC, 50-60Hz, 100VA
• Dimension: 340(L)*270(W)*160(H)
• Weight: 5KG
